We can customize all our pipe seals for your specific application. HRST has developed several retrofit pipe penetration seals to replace failed or damaged fabric seals, mechanical seals and stainless steel bellows type seals.

Mechanical Pipe Penetration Seals
(Roof or Floor)

  • Insulated housing and precision seal ring that can withstand high temperatures
  • Thermal sleeve for flexible interface with existing pipe insulation
  • Viewport for internal inspection
  • Split ‘clam shell’ housing and seal ring for ease of installation
  • No cutting or welding to pressure parts
  • No splicing of fabric belts
  • No delicate stainless steel bellows welding

High Temperature Fabric (HTF)
Pipe Penetration Seals (Roof or Floor)

  • No pressure part welding required
  • No bolted connections which eliminates need for gaskets
  • Durable, gas tight high-temperature PTFE coated outer fabric
  • Air-cooled metal components
  • Expansion friendly floor seal design
  • Robust insulation pillow under fabric that eliminates voids during operation
  • No special stitching or fabric tailoring required
  • Eliminates complicated internal insulation layering
  • Installation friendly for local mechanical contractors
  • No need to mobilize special installation team
  • Factory set dimensions and tolerances to simplify installation

Inverted Stainless Steel Bellows

HRST’s inverted bellows seal design eliminates trapped condensation in the insulation cavity area. The inverted bellows is located internal to the HRSG and connected to the casing via a pipe protrusion through the casing. The inside of HRST’s bellows is non-insulated, keeping it dry to prevent condensation corrosion. Not sure if corrosion is a problem? HRST’s Pulsed Eddy Current (PEC) for CUI allows assessment of piping conditions through non-magnetic materials such as lagging, insulation, and HRSG pipe penetration seals. If corrosion is found, consider HRST’s inverted bellows as a solution.
